FlexWorks Next Generation Supply Piping
50 Years of Unmatched Chemical Resistance Performance Packed into One Unique Pipe - KYNAR® (PVDF) + OPW = 15 Years of Excellence in Underground Pipe Performance.
Why a new pipe?
OPW Fueling Containment Systems has developed a Next Generation FlexWorks Pipe in response to the voice of the customer. You asked and we delivered! The new pipe is more flexible, lighter and has reduced memory.
-
Features & Benefits
What Makes This Pipe Different?
Lower installation costs
- Increased Pipe Flexibility – the force required to bend the pipe has been reduced to facilitate piping layout. This makes installation quicker and easier, especially in cold weather.
- Pipe Weight – has been reduced to facilitate shipping and handling
- Pipe Memory – Inherent pipe memory has been reduced significantly to facilitate connection of pipes inside sumps
- Redesigned Profile – enhanced leak detection performance
- Enhanced Kynar Pipe Liner – fluoropolymer chemical structure makes it dense and permeation resistant
UL Listings
FlexWorks double wall piping is listed with Underwriter's Laboratories under file #MH16678 and labeled as follows: Motor Vehicle Fuels, High Blend Fuels, Concentrated Fuels and Aviation and Marine.
UL Listed Warranted Fuels
Below are the listed fuels that have been tested under UL971 and are warranted for use with the FlexWorks Flexible Piping System.
Motor Vehicle Fuels
100% ASTM Reference Fuel No. 2 100% ASTM Reference Fuel C 85% Reference Fuel C - 15% MTBE 70% Reference Fuel C - 30% Ethanol 85% Reference Fuel C - 15% Methanol
High Blend Fuels
50% Reference Fuel C - 50% Methanol 50% Reference Fuel C - 50% Ethanol
Concentrated Fuels
100% Methanol 100% Ethanol 100% Toluene
Aviation and Marine Fuels
100% Premium Leaded Gas 100% Kerosene
* 3rd Party Approved for DEF
Listings and Certifications
Use your Enquiry Cart to make an enquiry, send your collection to a friend via email, or add your item into your wishlist.
Submit Enquiry
Submit a product Enquiry / Quote to Liquip customer serviceSave as Wishlist
Save as Wishlist - handy function for account holdersSend to a Friend
Send you selection of products to a friend via a convenient email link| Image | Item | Description |
Add Item into Enquiry Cart
|
|---|---|---|---|
|
C075A-1000 | Size(3/4"), Description(Double Wall Primary Pipe, 1000') | |
|
|
C075A-250 | Size(3/4"), Description(Double Wall Primary Pipe, 250') | |
|
|
C075A-SB | Size(3/4"), Description(Double Wall Primary Pipe 3/4" I.D. Short Box, 1' - 249') | |
|
|
C075A-SR | Size(3/4"), Description(Double Wall Primary Pipe 3/4" I.D. Short Reel, 260' - 490') | |
|
|
C10A-1000 | Size(1"), Description(Double Wall Primary Pipe, 1000') | |
|
|
C10A-250 | Size(1"), Description(Double Wall Primary Pipe, 250') | |
|
|
C10A-MR | Size(1"), Description(Double Wall Primary Pipe, Mega Reel, 2000') | |
|
|
C10A-SB | Size(1"), Description(Double Wall Primary Pipe 1.0" I.D. Short Box, 1' - 249') | |
|
|
C10A-SR | Size(1"), Description(Double Wall Primary Pipe 1.0" Short Reel, 20' - 990') | |
|
|
C15A-1000 | Size(1-1/2"), Description(Double Wall Primary Pipe, 1000') | |
|
|
C15A-1225 | Size(1-1/2"), Description(Stick Pipe 11/2" 12 Pieces At 25', 12 per box) | |
|
|
C15A-1233 | Size(1-1/2"), Description(Stick Pipe 11/2" 12 Pieces At 33', 12 per box) | |
|
|
C15A-1240 | Size(1-1/2"), Description(Stick Pipe 11/2" 12 Pieces At 40', 12 per box) | |
|
|
C15A-250 | Size(1-1/2"), Description(Double Wall Primary Pipe, 250') | |
|
|
C15A-500 | Size(1-1/2"), Description(Double Wall Primary Pipe, 500') | |
|
|
C15A-MR | Size(1-1/2"), Description(Double Wall Primary Pipe, Mega Reel, 1010' - 1400') | |
|
|
C15A-SB | Size(1-1/2"), Description(Double Wall Primary Pipe 1.5" I.D. Short Box, 50' - 240', 10' increments) | |
|
|
C15A-SR | Size(1-1/2"), Description(Double Wall Primary Pipe 1.5" I.D. Short Reel, Less than 500', 10' increments) | |
|
|
C20A-1225 | Size(2"), Description(Stick Pipe 2.0" Double Wall 12 Pieces At 25', 12 per box) | |
|
|
C20A-1233 | Size(2"), Description(Stick Pipe 2.0" Double Wall 12 Pc @ 33', 12 per box) | |
|
|
C20A-250 | Size(2"), Description(Double Wall Primary Pipe, 250') | |
|
|
C20A-500 | Size(2"), Description(Double Wall Primary Pipe, 500') | |
|
|
C20A-MR | Size(2"), Description(Double Wall Primary Pipe, Mega Reel, 800', 510'- 800', 10' increments) | |
|
|
C20A-SB | Size(2"), Description(Double Wall Primary Pipe, 2.0" I.D. Short Box, 50' - 240', 10' increments) | |
|
|
C20A-SR | Size(2"), Description(Double Wall Primary Pipe, 2.0" I.D. Short Reel, 260'- 490', 10' increments) | |
|
|
C30A-200 | Size(3"), Description(Call For Availability. 3" Double Wall Primary Pipe, Lengths up to 200') | |
|
|
C30A-MR | Size(3"), Description(3" Double Wall Primary Pipe, 200' to Max 350') | |
|
|
C30A-SR | Size(3"), Description(Call For Availability. 3" Double Wall Primary Pipe, Lengths up to 200') | |
|
|
CO75A-MR | Size(3/4"), Description(Double Wall Primary Pipe, Mega Reel, 2000') |
